Description

ECCO 5.5KW 48V 100A MPPT Hybrid Solar Inverter.

Features

– Pure Sine Wave Solar Inverter

– Output Power Factor 1

– High PV Input Voltage Range (120VDC – 500VDC)

– Built-in 100A MPPT Solar Controller

– Supports Multiple Output Priority: UTL, SOL, SBU, SUB

– Parallel Operation with Up to 12 units (Parallel Version)

– Supports Parallel Operation in Single Phase/ 3 Phase (Parallel Version)

– Supports Wireless Parallel, Without Extra Sharing Current Cable

– RS485 Communication for BMS

– Wifi Monitoring

– Battery Equalization Function to Optimise Battery Performance and Extended Lifecycle



Specifications:-

Inverter Mode

– Rated Power: 5500VA / 5500W

– DC Input: 48VDC, 127A

– AC Output: 230VAC, 50/60Hz, 23.9A

AC Charger Mode

– AC Input: 230VAC, 50/60Hz, 40A

– DC Output: 54VDC

– Max. Charge Current(AC): 60A Default 30A

– Max. Charge Current(PV+AC): 100A

– AC Output: 230VAC, 50/60Hz, 23.9A



Solar Charge Mode

– Max. PV Array Power: 5500W

– Min. Solar Voltage: 120VDC

– Max. Solar Voltage (VOC): 500VDC

– Max. MPPT Charge Current: 100A



Ingress Protection: IP21 (Indoor Use)



Dimensions ; 38 x 55 x 20 cm

Weight : 9.65kg.



Warranty

• 5-Year Warranty: Warranty is only valid when a certified electrician installs the product and a CoC is issued.
