Description

Cells: 144 Cells (6 x 24)
Type: Mono PERC
Dimensions: 2112 x 1052 x 35 mm
Weight: 24.7 kg
Max. load: 5400 Pa
Junction Box: IP67 rated, 3 diodes
Frame: Silver
Connection: MC4

Electrical Characteristics

Nominal Output (Pmax): 460 W
Voltage at Pmax (Vmp): 42.13 V
Current at Pmax (Imp): 10.96 A
Open Circuit Voltage (Voc): 50.01 V
Short Circuit Voltage (Isc): 11.45 A
Max. system voltage: 1000/1500 VDC
Max. series fuse rating: 20 A
Module efficiency: 20.7 %
Features:

High output power
Less shading effect
Lower temperature coefficient
Better mechanical loading tolerance
Efficiency of 20.2%
Power output temperature coefficient: 0.35%
Multi 9 busbar
Silver frame with white backsheet
12 Year product warranty and 25 year linear power output warranty.
